Description
| In. | I.D. In. |
Wall In. |
Wt./Ft. (lbs.) |
Part No. |
| 1/4 | 0.180 | .035 | 0.208 | 03-31600 |
| 5/16 | 0.243 | .035 | 0.037 | 03-31700 |
| 5/16 | 0.215 | .049 | 0.049 | 03-31800 |
| 3/8 | 0.305 | .035 | 0.045 | 03-32000 |
| 3/8 | 0.277 | .049 | 0.060 | 03-32100 |
| 3/8 | 0.245 | .065 | 0.076 | 03-32200 |
| 1/2 | 0.430 | .035 | 0.061 | 03-32500 |
| 1/2 | 0.402 | .049 | 0.083 | 03-32600 |
| 1/2 | 0.384 | .058 | 0.097 | 03-32700 |
| 1/2 | 0.370 | .065 | 0.106 | 03-32800 |
| 5/8 | 0.555 | .035 | 0.078 | 03-32900 |
| 5/8 | 0.527 | .049 | 0.106 | 03-33000 |
| 5/8 | 0.509 | .058 | 0.123 | 03-33100 |
| 5/8 | 0.495 | .065 | 0.137 | 03-33200 |
| 3/4 | 0.680 | .035 | 0.094 | 03-33300 |
| 3/4 | 0.652 | .049 | 0.129 | 03-33400 |
| 3/4 | 0.620 | .065 | 0.167 | 03-33600 |
| 7/8 | 0.805 | .035 | 0.142 | 03-33650 |
| 7/8 | 0.777 | .049 | 0.153 | 03-33700 |
| 7/8 | 0.759 | .058 | 0.178 | 03-33800 |
| 7/8 | 0.745 | .065 | 0.198 | 03-33900 |
| 7/8 | 0.635 | .120 | 0.340 | 03-34000 |
| 1 | 0.930 | .035 | 0.125 | 03-34100 |
| 1 | 0.902 | .049 | 0.175 | 03-34200 |
| 1 | 0.884 | .058 | 0.203 | 03-34250 |
| 1 | 0.870 | .065 | 0.230 | 03-34400 |
| 1 | 0.834 | .083 | 0.287 | 03-34500 |
| 1-1/4 | 1.180 | .035 | 0.160 | 03-34600 |
| 1-1/4 | 1.152 | .049 | 0.223 | 03-34700 |
| 1-1/4 | 1.120 | .065 | .3000 | 03-00045 |
| 1-3/8 | 1.277 | .049 | 0.245 | 03-34800 |
| 1-1/2 | 1.402 | .049 | 0.268 | 03-34900 |
| 1-1/2 | 1.370 | .065 | 0.352 | 03-35000 |
| 1-3/4 | 1.250 | .250 | 1.428 | 03-35075 |
| 2 | 1.870 | .065 | 0.474 | 03-35200 |
